Manual Leveling Machine (200mm Roll Diameter)

Product Introduction

The Φ200mm Manual Leveling Machine is a heavy-duty specialized machine designed specifically for the precise straightening of medium- and heavy-gauge steel plates. Featuring an extra-large-diameter work roll as its key highlight, It delivers high rigidity, high precision, and excellent cost-effectiveness for thick plate leveling, and is widely applicable to the plate straightening needs of various industries, including steel structure fabrication, heavy machinery manufacturing, and ship component production. It is the preferred solution for small and medium-sized enterprises seeking efficient, low-cost leveling of medium- and heavy-gauge plates.

Applications

1. Extra-large roll diameter for more stable and powerful thick plate leveling

• The Φ200mm work roll is crafted from high-strength alloy steel, offering rigidity far surpassing that of conventional equipment with smaller roll diameters. It resists deformation during the leveling process, effortlessly eliminating various distortions in thick plates—such as waviness, camber, and twisting—while minimizing surface indentations. This achieves the dual benefits of “thorough leveling + undamaged surface,” making it specifically designed for heavy-duty plate processing applications.

2. High-Precision Alignment to Meet Demanding Processing Requirements

• Using Q235 steel as a benchmark, the leveling accuracy is consistently maintained at 0.1–0.15 mm/mm. This meets the stringent flatness requirements of industries such as steel structures, heavy machinery, and shipbuilding components, providing reliable assurance for subsequent welding, cutting, and assembly processes while preventing finished product quality issues caused by plate deformation.

3. Flexible Adaptability, Covering Multiple Processing Scenarios

• Standard widths range from 200–2100 mm, accommodating plates of various specifications;

• Optional 15- or 19-roll configurations allow for flexible adjustment of leveling force to suit plates of different thicknesses, materials, and degrees of deformation;

• Minimum workpiece length of just 310 mm supports the leveling of short pieces and scrap material, improving material utilization and reducing production costs.

4. Efficient and Convenient, Balancing Production and Cost

• Steplessly adjustable line speed from 1–10 m/min accommodates different paces for trial leveling and batch production;

• Manual worm gear fine-tuning mechanism + dial gauge dynamic indication ensures simple, intuitive operation requiring no complex training;

• Stable structure with no redundant automation modules ensures low failure rates and easy maintenance. Initial investment costs are significantly lower than those of fully automatic heavy-duty leveling equipment, making it suitable for the budgets and production needs of small and medium-sized enterprises and individual workshops.

5. Expandable and upgradeable to support long-term growth

• Supports full-process customized upgrades and can be integrated with accessories such as automatic loading/unloading robots, roller conveyors, and coil-to-sheet lines to form an integrated processing line. This enables efficient processing from coil to finished product, meeting enterprises’ future needs for capacity expansion and automation upgrades.


Technical Specifications

Applicable Industries and Applications

• Steel Structure Fabrication: Straightening of thick steel plates and structural steel required for industrial buildings, bridges, tower cranes, and steel structural components to ensure welding and installation accuracy;

• Heavy Machinery Manufacturing: Straightening of thick plates for equipment bases, supports, and large components to ensure precise assembly dimensions;

• Shipbuilding / Mining Machinery: Straightening of thick plates for decks, hull components, and mining equipment to counteract the effects of heavy loads and corrosive environments on plate precision;

• Sheet Metal Recycling and Repair: Secondary straightening of scrap thick steel plates and equipment panels to facilitate resource reuse and reduce raw material costs;

• Customized Production Line Integration: Can be integrated with decoilers and laser cutting lines to form an integrated decoiling-straightening-blanking processing line, enhancing production efficiency.

List of Optional Accessories

• Automation Units: Automatic loading/unloading manipulators and palletizing robots to reduce manual intervention;

• Conveyor Systems: Powered and non-powered roller conveyor lines to ensure smooth sheet feeding and unloading;

• Custom Roll Sets: Number and configuration of leveling rolls can be adjusted as needed to accommodate special sheet processing requirements;

• Uncoiling and Blanking Lines: Hydraulic or mechanical uncoilers and laser cutting/blanking lines to enable integrated coil processing.
